Instruments
The Faculty of Science NMR Facility is well equipped with both solids and liquids instruments from 200 to 600 MHz. We have instruments for routine use, as well as, instruments requiring more user input.
Spectrometers
Bruker Avance 300
- Bioscience 411
- Liquids 1H/13C/31P/19F/2H QNP probe with Z gradient
Bruker Avance II 300
- Bioscience 411
- Liquids autotuning broadband probe (BBFO) with Z gradient
Bruker AVANCE II 400
- Bioscience 411
- Robotic sample changer for up to 60 samples
- 5mm autotuning broadband probe (BBFO) with Z gradient
Bruker AVANCE III HD 500
- STEM 0028
- Solids 4 mm triple resonance MAS probe
- Solids 4 mm low frequency double resonance MAS probe
- Solids 7 mm MAS probe (to accommodate air sensitive samples)
- Solids wideline probe
- Liquids inverse broadband probe with Z gradient
- Liquids broadband probe with Z gradient
- Triple resonance H/C/N probe with Z gradient
Bruker Avance III HD 600
- D'Iorio 416
- Liquids 5 mm triple resonance H/C/N autotuning cryoprobe
- Liquids 5 mm triple resonance H/C/N autotuning room temperature probe
Bruker Avance III 200
- D'Iorio 416
- Solids only
- Solids 7 mm triple resonance MAS probe
- Solids 7 mm MAS probe (to accommodate air sensitive samples)
- Solids wideline probe
- CRAMPS probe
Bruker Avance III 400
- STEM 0028
- Solids only
- 4 mm triple resonance MAS probe
- 7 mm low frequency double resonance MAS probe
- Wideline probe
- DOR probe
- Single crystal probe
Bruker EMX plus EPR
- STEM 0028
- Liquid helium cryostat
Bruker Fourier 300
- Marion 313
- For Undergraduate lab use
- 5mm dual probe with Z gradient
